Samsung Galaxy Z Flip Specs

5.0

PhoneArena Score

Samsung Galaxy Z Flip Review

User Score

Be the first to review this phone

Add Review

Released

Feb 14, 2020

Display

6.7-inch
2636 x 1080 px

Camera

12 MP Main
10 MP Selfie

Battery

3300 mAh

Storage

256GB

Hardware

Qualcomm Snapdragon 855+
8GB RAM

OS

Android 12
Samsung One UI

Description

The 6.7-inch display of the Galaxy Z Flip bends around the horizontal axis and has just a small 1.1" screen on the outside for date/time/notification purposes. Under the hood, the phone offers Snapdragon 855+ with 8GB and 256GB storage. 3300mAh battery is keeping the lights on, and Android 10 is preinstalled out of the box. There is a dual-camera setup on the back, two 12MP sensors (wide + ultra-wide angle). The price of the Galaxy Z Flip is $1380.

This device is also known as Samsung SM-F700U, Samsung Galaxy Z Flip Thom Browne Edition

Pros

Supports wireless charging

I want it 9 users

I have it 1 user

I had it 0 users

Deals

$389

Popular Comparisons

The is most commonly compared with these phones:

Specs Compare

Display Benchmarks
Size:	6.7-inch
Resolution:	2636 x 1080 px, 22:9 ratio, 425 PPI
Technology:	Dynamic AMOLED
Screen-to-body:	81.04 %
Features:	HDR support, Ambient light sensor, Proximity sensor
Additional display:	1.1 inches, 112 pixels 300 x, Super AMOLED

Hardware Benchmarks
System chip:	Qualcomm Snapdragon 855+ SM8150-AC (7 nm)
Processor:	Octa-core, 1x 2.96GHz Kryo 485 + 3x 2.42GHz Kryo 485 + 4x 1.80GHz Kryo 485, 64-bit
GPU:	Adreno 640
RAM:	8GB (LPDDR4)
Internal storage:	256GB, available to use: 224 GB, not expandable
OS:	Android (12, 11, 10), Samsung One UI
Device type:	Smartphone

Battery Benchmarks
Capacity:	3300 mAh
Type:	Li - Polymer, Not user replaceable
Battery life test results:	link
Charging:	Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi wireless charging, Reverse wireless charging

Camera
Rear:	Dual camera
Main camera:	12 MP (OIS, PDAF)
Specifications:	Aperture size: F1.8 Focal length: 27 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Second camera:	12 MP (Ultra-wide)
Specifications:	Aperture size: F2.2 Pixel size: 1.12 μm
Flash:	LED
Video recording:	3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features:	HDR, Time-lapse video, Hyperlapse, Continuous autofocus, EIS
Front:	10 MP
Video capture:	3840x2160 (4K UHD) (30 fps)

Design Size comparison
Dimensions:	6.59 x 2.90 x 0.28 inches (167.3 x 73.6 x 7.2 mm)
Folded:	(87.4 x 73.6 x 17.3 mm)
Weight:	6.46 oz (183.0 g)
Materials:	Frame: Aluminum
Resistance:	None
Biometrics:	2D Face unlock, Fingerprint (touch)
Keys:	Right: Volume control, Lock/Unlock key
Colors:	Mirror black, Mirror purple

Cellular
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD):	Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
3G:	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed:	LTE-A Pro Cat 16 (1000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM:	Yes
SIM type:	Nano SIM, eSIM
HD Voice:	Yes

Multimedia
Headphones:	No 3.5mm jack
Speakers:	Earpiece, Multiple speakers
Features:	Dolby Atmos, Dolby Digital, Dolby Digital Plus
Screen mirroring:	Wireless screen share
Additional microphone(s):	Noise cancellation

Connectivity & Features
Bluetooth:	5.0
Wi-Fi:	802.11 a, b, g, n, ac, dual-band MIMO, Wi-Fi Direct, Hotspot
USB:	Type-C (reversible), USB 2.0
Features:	Charging, Headphones port, OTG
Hearing aid compatible:	M3, T3
Location:	GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors:	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other:	NFC, ANT+

Regulatory Approval
FCC approval:
Date approved:	Feb 05, 2020
FCC ID value:	A3LSMF700U
Measured SAR:
Head:	0.26 W/kg
Body:	0.96 W/kg
Simultaneous Transmission:	1.47 W/kg
Wireless Router:	1.39 W/kg
Phablet:	3.87 W/kg

Buyers information
Price:	$ 1380
User Manual:	This is the official Samsung Galaxy Z Flip User Guide in English provided from the manufacturer.
In The Box:	Charger and cable, OTG, SIM ejector tool, Protector, USB-C headphones.

Availability
Officially announced:	Feb 11, 2020

Despite our efforts to provide full and correct specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Samsung Galaxy Z Flip

Thom Browne Edition

Differences from the main variant:
Colors:	Grey
Price:	$ 2480
In The Box:	Leather Cover, Galaxy Watch Active2 and two straps, Galaxy Buds+

Samsung Galaxy Z Flip

for AT&T

Differences from the main variant:
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)

Samsung Galaxy Z Flip

for Sprint

Differences from the main variant:
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3), 71(600)
