Samsung Galaxy Note 20 Specs

8.0

PhoneArena Score

Samsung Galaxy Note 20 Review

User Score

Be the first to review this phone

Add Review

Released

Aug 21, 2020

Display

6.7-inch
2400 x 1080 px

Camera

12 MP Main
10 MP Selfie

Battery

4300 mAh

Storage

128GB

Hardware

Qualcomm Snapdragon 865+
8GB RAM

OS

Android 13
Samsung One UI

Description

The Samsung Galaxy Note 20 specs include Snapdragon 865 chipset and an Exynos one to match in all non-US regions accompanied by 8GB of RAM and up to 256GB storage, and 4300mAh battery. At the back is situated the triple-camera setup from the Galaxy S20. A 6.7-inch sAMOLED display with a 60Hz refresh rate is at the front. S Pen and 5G come off as standard. The Galaxy Note 20 is available for starting price of $1000.

This device is also known as Samsung SM-N981U

Pros

5G ready
High screen-to-body ratio (89.23 %)
Supports wireless charging

I want it 0 users

I have it 0 users

I had it 0 users

Deals

$258

$248

$335

Popular Comparisons

The is most commonly compared with these phones:

Specs Compare

Display Benchmarks
Size:	6.7-inch
Resolution:	2400 x 1080 px, 20:9 ratio, 393 PPI
Technology:	Super AMOLED Plus
Refresh rate:	60Hz
Screen-to-body:	89.23 %
Features:	HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor

Hardware Benchmarks
System chip:	Qualcomm Snapdragon 865+ SM8250-AB (7 nm)
Processor:	Octa-core, 1x 3.1GHz Kryo 585 + 3x 2.42GHz Kryo 585 + 4x 1.80GHz Kryo 585, 64-bit
GPU:	Adreno 650
RAM:	8GB (LPDDR5)
Internal storage:	128GB (UFS 3.0), available to use: 102.5 GB, not expandable
OS:	Android (13, 12, 11, 10), Samsung One UI Screenshots
Device type:	Smartphone

Battery Benchmarks
Capacity:	4300 mAh
Type:	Li - Polymer, Not user replaceable
Battery life test results:	link
Charging:	Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging

Camera
Rear:	Triple camera Camera samples
Main camera:	12 MP (OIS, PDAF)
Specifications:	Aperture size: F1.8 Focal length: 26 mm Sensor size: 1/1.76" Pixel size: 1.8 μm
Second camera:	64 MP (Telephoto, OIS, PDAF)
Specifications:	Aperture size: F2.0 Focal Length: 27 mm Sensor size: 1/1.7" Pixel size: 0.8 μm
Third camera:	12 MP (Ultra-wide, Autofocus)
Specifications:	Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Flash:	LED
Video recording:	7680x4320 (8K UHD) (24 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features:	OIS, HDR, Time-lapse video, Hyperlapse, Object tracking, EIS
Front:	10 MP (PDAF, HDR)
Video capture:	3840x2160 (4K UHD)

Design Size comparison
Dimensions:	6.36 x 2.96 x 0.33 inches (161.6 x 75.2 x 8.3 mm)
Weight:	6.84 oz (194.0 g)
Materials:	Back: Plastic
Resistance:	Water, Dust; IP68
Biometrics:	2D Face unlock, Ultrasonic in-screen fingerprint
Features:	Stylus
Keys:	Right: Volume control, Lock/Unlock key
Colors:	Mystic gray, Mystic bronze, Mystic green, Mystic red

Cellular
5G:	Bands n2, n5, n12, n25, n41, n66, n71, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)
4G (TDD):	Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G:	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed:	LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type:	Nano SIM
HD Voice:	Yes

Multimedia
Headphones:	No 3.5mm jack
Speakers:	Earpiece, Multiple speakers
Features:	32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus
Screen mirroring:	Wireless screen share
Radio:	FM
Additional microphone(s):	Noise cancellation

Connectivity & Features
Bluetooth:	5.0
Wi-Fi:	802.11 a, b, g, n, ac, ax(Wi-Fi 6), dual-band MIMO, Wi-Fi Direct, Hotspot
USB:	Type-C (reversible), USB 3.2
Features:	Charging, Headphones port, OTG, Video out
Hearing aid compatible:	M3, T3
Location:	GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors:	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other:	NFC, ANT+

Regulatory Approval
FCC approval:
Date approved:	Jul 22, 2020
FCC ID value:	A3LSMN981U
Measured SAR:
Head:	0.41 W/kg
Body:	0.92 W/kg
Simultaneous Transmission:	1.59 W/kg
Wireless Router:	1.22 W/kg
Phablet:	3.99 W/kg

Buyers information
Price:	$ 1000
User Manual:	This is the official Samsung Galaxy Note 20 User Guide in English provided from the manufacturer.
In The Box:	Data Cable, Travel Adapter, Ejection Pin, Quick Start Guide

Availability
Officially announced:	Aug 05, 2020

Despite our efforts to provide full and correct Samsung Galaxy Note 20 specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Samsung Galaxy Note 20

For Europe

Differences from the main variant:
System chip:	Samsung Exynos 990 (7 nm)
Processor:	Octa-core, 2x 2.73GHz Exynos M5 + 2x 2.5GHz Cortex-A76 + 4x 2.0 GHz Cortex-A55, 64-bit
GPU:	Mali G77 MP11
Internal storage:	256GB
FCC approval:
Date approved:	Jul 16, 2020
FCC ID value:	A3LSMN981B
Measured SAR:
Head:	0.29 W/kg
Body:	0.72 W/kg
Simultaneous Transmission:	1.60 W/kg
Wireless Router:	1.24 W/kg
Phablet:	1.93 W/kg
Price:	€ 1023
