OnePlus 7T Pro 5G McLaren Specs

7.7

Description

The OnePlus 7T Pro 5G McLaren Edition features a notch-less 6.67-inch Fluid AMOLED display with a 1440 x 3120 resolution. The phone carries a 90Hz screen and is powered by the overclocked Snapdragon 855+ chipset. The OnePlus 7T Pro 5G McLaren Edition is equipped with 12GB of memory and 256GB of storage. There is a triple-camera set up in the back (48MP primary + 16MP ultra-wide+8MP telephoto). A 4085mAh battery keeps the lights on and charges quickly with Warp Charge 30T. The McLaren is priced at $899.99.

Pros

  • 5G ready
  • High screen-to-body ratio (88.46 %)
  • High pixel density screen (515 PPI)
I want it 6 users
I have it 8 users
I had it 3 users

Popular Comparisons

The is most commonly compared with these phones:

Specs Compare

Display

Size: 6.7-inch
Resolution: 3120 x 1440 px, 19.5:9 ratio, 515 PPI
Technology: AMOLED
Refresh rate: 90Hz
Screen-to-body: 88.46 %
Features: HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor

Hardware

System chip: Qualcomm Snapdragon 855+ SM8150-AC (7 nm)
Processor: Octa-core, 2960 MHz, Kryo 485, 64-bit
GPU: Adreno 640
RAM: 12GB (LPDDR4)
Internal storage: 256GB (UFS 3.0), not expandable
OS: Android (10)
Device type: Smartphone

Battery

Capacity: 4085 mAh
Type: Li - Ion, Not user replaceable
Charging: OnePlus Warp Charge
Max charge speed: Wired: 30.0W

Camera

Rear: Triple camera
Main camera: 48 MP (OIS, Laser and PDAF)
Specifications: Aperture size: F1.6
Sensor size: 1/2"
Pixel size: 0.8 μm
Second camera: 8 MP (Telephoto, OIS)
Specifications: Optical zoom: 3.0x
Aperture size: F2.4
Pixel size: 1 μm
Third camera: 16 MP (Ultra-wide)
Specifications: Aperture size: F2.2
Focal Length: 17 mm
Flash: Dual LED
Video recording: 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features:
Time-lapse video, Continuous autofocus, EIS
Front: 16 MP (Pop-up, HDR)
Video capture: 1920x1080 (Full HD)
Dimensions: 6.40 x 2.99 x 0.35 inches
(162.6 x 75.9 x 8.8 mm)
Weight: 7.41 oz (210.0 g)
Materials: Back: Glass (Corning Gorilla Glass 5)
Frame: Metal
Biometrics: 2D Face unlock, Optical in-screen fingerprint
Keys: Left: Volume control; Right: Lock/Unlock key
Colors: Papaya orange

Cellular

5G: Bands n41, n71
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD): Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G: Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed: LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM: Yes
SIM type: Nano SIM
HD Voice: Yes

Multimedia

Headphones: No 3.5mm jack
Speakers: Earpiece, Multiple speakers
Features: Dolby Atmos, aptX-HD
Screen mirroring: Wireless screen share
Additional microphone(s): Noise cancellation

Connectivity & Features

Bluetooth: 5.0
Wi-Fi: 802.11 a, b, g, n, ac, dual-band
MIMO, Wi-Fi Direct, Hotspot
USB: Type-C (reversible), USB 3.1
Features: Charging, Headphones port
Hearing aid compatible: M3, T3
Location: GPS, A-GPS, Glonass, Galileo, BeiDou, Dual-band positioning, Cell ID, Wi-Fi positioning
Sensors: Accelerometer, Gyroscope, Compass
Other: NFC

Regulatory Approval

FCC approval:
Date approved: Nov 22, 2019
FCC ID value: 2ABZ2-EE143
Measured SAR:
Head: 0.95 W/kg
Body: 0.90 W/kg
Simultaneous Transmission: 1.41 W/kg
Wireless Router: 0.99 W/kg
Phablet: 2.84 W/kg

Buyers information

Price: $ 900
In The Box: Warp Charge Type-C USB Cable, Warp Charge 30 Power Adapter, McLaren Protective Case, SIM Tool, Quick Start Guide, Terms & Conditions, Safety Information & Warranty Card

Availability

Officially announced: Dec 06, 2019
Despite our efforts to provide full and correct OnePlus 7T Pro 5G McLaren specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Carrier Availability

Discontinued

T-Mobile

News

2019's OnePlus 7, 7T series to receive update to Android 12
Owners of the OnePlus 7 and OnePlus 7T series have to be happy with the news that a bug that caused the delayed display of incoming calls on those handsets has finally been exterminated. The update to OxygenOS 11.0.4.1 includes a fix for this bug alo...
, by Alan Friedman, 1
2019's OnePlus 7, 7T series to receive update to Android 12
The stunning OnePlus 7T Pro 5G McLaren is on sale at a huge discount
The last McLaren-branded OnePlus smartphone ever manufactured is no longer available from its exclusive US carrier, but if you're still mesmerized by the very unique design of that particular 7T Pro version, both the handset maker itself and B&H ...
, by Adrian Diaconescu, 0
The stunning OnePlus 7T Pro 5G McLaren is on sale at a huge discount
-$500
T-Mobile delivers tardy Android 11 update to swanky OnePlus 7T Pro 5G
While the decidedly eye-catching and unconventional OnePlus 7T Pro 5G McLaren Edition was obviously never meant to appeal to the masses, the T-Mobile subscribers that spent a whopping $900 on the Snapdragon 855+ powerhouse less than a year and a half...
, by Adrian Diaconescu, 1
T-Mobile delivers tardy Android 11 update to swanky OnePlus 7T Pro 5G
T-Mobile starts pushing out another OnePlus software update
T-Mobile has been rolling out software updates like crazy in the last week or so. OnePlus and Samsung smartphones, including those featuring 5G support, have been updated with tweaks meant to improve various aspects.Today, the Un-carrier released yet...
, by Cosmin Vasile, 0
T-Mobile starts pushing out another OnePlus software update

User Reviews

Overall User Rating
Build quality
10
Camera quality
6
Performance
9.7
Display
10
Battery life and charging
6.7
Rating breakdown (out of 10)
9
Great Device all around
Phone owned for less than a year

Gotta say, I really like this phone. The looks and the experience is top notch. I have been using this phone for about 3.5 months now and the only bad thing I could say is that the battery does seem to drain a bit too fast; which of course is a big deal, but thankfully a 5-7 minute charge will bring the battery from 30% to 55%, but I worry about the battery's longevity.

Overall, the user experience of the phone is great, and the build is great as well... The case that comes along with it is also great and gives a good and snug feel to it.

If you need longer battery life out of this phone, you will have to change the screen refresh rate to 60 and turn off 5g, and I gotta say, while those features are great, they are very power hungry. Thankfully this phone is still a great device overall; even if you gotta sacrifice the extra cool features every now and then.

I don't live in a 5g area, but I will say that when I traveled through Nevada in the first days of having this phone, it did seem to struggle with keeping a GPS signal. I mention that because it seems 5g is causing some GPS issues... I cannot confirm that the issue has been resolved, but I have already received an update about a month ago that claimed to have solved it. And also note that T-mobiles 5g network is not yet a standalone feature. Meaning that, you'll still be connected to 4g while using 5g and it seemed to cause some issues when I got to test it out on my road trip... buut, there has been an update to supposedly improve network stability, but again, its not something I can confirm yet.

Read Full Review
9
the best phone that i have had so far.
Phone owned for less than 3 months

This is the first one plus Phone that have owned. I do have to say that after having a sony XZ2 that this is hand down the best phone that I have had. The design of the phone is the best that I have had. now it has not been a smooth ride though with a few updates OnePlus has updated this phone and i am b=getting great battery life out of the phone.

Read Full Review
5
Great hardware spoiled by poor software
Phone owned for less than a month

Firstly, good impression count. The packaging of the McLaren edition is beautiful. It comes in the McLaren papaya orange branding. Inside you get the leaflets, a McLaren branded charger and charging cable, a SIM tray tool, a McLaren protective back cover (which is cleverly hidden away in another compartment) and the handset itself.
The handset itself is beautiful. The McLaren branding is not obvious unless you look at the back of the handset. The amalgamation of glass and metal makes the 7T Pro McLaren handset look super cool and expensive. The orange highlights are presented around the edge of the phone, the slider switch and around the camera lens assembly. There’s the USB-C port (no headphone ports here), a speaker at both ends. A rocker switch is present on the left hand side acting as the volume control and the on/off button on the right. So far so good.
The 6.67” display is spectacular (and it is factory fitted with a screen protector). Power it on and you’re greeted by an OnePlus logo followed by a McLaren logo.. The 90hz screen refresh may sound like a gimmick but once you’ve used it, you won’t go back to using the 60hz setting. Loading up YouTube videos, Netflix or your own pre-recorded content looks superb. The built-in speakers are loud and don’t distort.
The Oxygen operating system is based on Android 10 out of the box. It is sleek and quick. There’s no jarring performance bottlenecks switching from one screen to another.
The battery is rated at 4085 mah. It sounds big but remember the screen size factored in with the 90hz refresh rate will drain it quickly. There are plenty of optimization facilities available to help conserve battery life. The Warp charger helps to recharge the 7T Pro McLaren from 0 to 100% in just over an hour.
At this point you may have noticed I haven’t mentioned connectivity nor the camera. This is where the McLaren falls down spectacularly.
The camera set-up on the 7T Pro looks great on paper. Once you start taking pictures though, well, my LG G4 takes better pictures. Images aren’t detailed and lack dynamic range. Sometimes, the photographs take at least a second or two to be captured – really? Yes, the camera set-up is slow. You can only use the 48MP sensor on Pro Mode and even then it’s a ratio of 4:3 – that isn’t mentioned anywhere in OP’s literature. The macro mode for close-ups is a gimmick and doesn’t work particularly well. The wide angle lens is blurred at the edges.
Video capture isn’t bad but it’s not great either but image stabilization probably one of the best as long as you don’t move the handset wildly around otherwise you’ll see blurring.
As for connectivity – the handset constantly drops its connection from WiFi and cell network. 5G does not work properly. GPS is useless.
The Warp charger decided to give up after a few weeks. OnePlus weren't interested in supplying a replacement.
The old saying beauty is only skin deep applies to the 7T Pro McLaren edition. Don't buy it.

Read Full Review
