Apple iPhone 16 Pro Max Specs

Released

Sep 20, 2024

Display

6.9-inch
2868 x 1320 px

Camera

48 MP Main
12 MP Selfie

Battery

4685 mAh

Storage

256GB

Hardware

Apple A18 Pro
8GB RAM

OS

iOS 18.x

Description

The iPhone 16 Pro Mx comes with 6.9-icnh OLED display with 120Hz refresh rate and Apple's A18 Pro processor. Specs also include Triple camera setup on the back and better battery life than the previous model.

8.0

PhoneArena Score

Apple iPhone 16 Pro Max Review

6.0

User Score (3 reviews)

Add Review

I want it 35 users

I have it 22 users

I had it 3 users

Deals

Deal

82%off $5

$630off $569

View more offers

Popular Comparisons

The Apple iPhone 16 Pro Max is most commonly compared with these phones:

Specs Compare

Display Benchmarks
Size:	6.9-inch
Resolution:	2868 x 1320 px, 19.5:9 ratio, 458 PPI
Technology:	OLED
Refresh rate:	Variable 1-120Hz
Screen-to-body:	92.35 %
Peak brightness:	2000 cd/m2 (nit)
Features:	Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass (Ceramic Shield), Ambient light sensor, Proximity sensor

Hardware
System chip:	Apple A18 Pro (3 nm)
Processor:	Hexa-core, 2x 4.05GHz + 4x 2.42GHz
GPU:	Apple 6-core GPU
RAM:	8GB (LPDDR5)
Internal storage:	256GB (NVMe), not expandable
OS:	iOS (18.x)
Device type:	Smartphone

Battery Benchmarks
Capacity:	4685 mAh
Type:	Li - Ion, Not user replaceable
Charging:	Fast charging, Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging
Max charge speed:	Wired: 27.0W Wireless: 25.0W

Camera Benchmarks
Rear:	Triple camera
Main camera:	48 MP (Sensor-shift OIS, PDAF)
Specifications:	Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 1.22 μm
Second camera:	12 MP (Telephoto, Periscope, Sensor-shift OIS, PDAF)
Specifications:	Optical zoom: 5.0x Aperture size: F2.8 Focal Length: 120 mm Sensor size: 1/3.06" Pixel size: 1.12 μm
Third camera:	48 MP (Ultra-wide)
Specifications:	Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/3.06" Pixel size: 0.7 μm
Flash:	Dual LED
Video recording:	3840x2160 (4K UHD) (120 fps), 1920x1080 (Full HD) (240 fps)
Features:	OIS, HDR, Continuous autofocus, Picture-taking during video recording, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
Front:	12 MP (Time-of-Flight (ToF), Autofocus, HDR)
Video capture:	3840x2160 (4K UHD) (60 fps)

Design Size comparison
Dimensions:	6.42 x 3.05 x 0.33 inches (163.0 x 77.6 x 8.25 mm) thickness with camera 0.48 inches (12.25 mm)
Weight:	8.01 oz (227.0 g)
Materials:	Back: Glass Frame: Titanium
Resistance:	Water, Dust; IP68
Biometrics:	3D Face unlock
Keys:	Left: Volume control, Other; Right: Lock/Unlock key, Other
Colors:	Black Titanium, White Titanium, Natural Titanium, Desert Titanium

Cellular
5G:	Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD):	Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 46, 48(3600)
3G:	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed:	LTE-A Pro Cat 18 (1200/150 Mbit/s)
SIM type:	eSIM
HD Voice:	Yes
VoLTE:	Yes

Multimedia
Headphones:	No 3.5mm jack
Speakers:	Earpiece, Multiple speakers
Features:	Dolby Atmos
Screen mirroring:	Wireless screen share
Additional microphone(s):	Noise cancellation

Connectivity & Features
Bluetooth:	5.3
Wi-Fi:	802.11 a, b, g, n, ac, ax(Wi-Fi 6), Wi-Fi 7, Wi-Fi 6E Wi-Fi Direct, Hotspot
USB:	Type-C (reversible), USB 3.2
Features:	Charging
Hearing aid compatible:	M3, T4
Location:	GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning, Emergency SOS via satellite (SMS sending/receiving)
Sensors:	Accelerometer, Gyroscope, Compass, Barometer
Other:	NFC, Ultra Wideband (UWB)

Regulatory Approval
FCC approval:
Date approved:	Sep 09, 2024
FCC ID value:	BCG-E8684A
Measured SAR:
Head:	0.96 W/kg
Body:	0.98 W/kg
Simultaneous Transmission:	0.99 W/kg

Buyers information
MSRP:	$ 1199 / € 1449
In The Box:	USB-C Charge Cable (1 m), Documentation

Availability
Officially announced:	Sep 09, 2024

Despite our efforts to provide full and correct Apple iPhone 16 Pro Max specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Apple iPhone 16 Pro Max

With 512GB internal storage

Differences from the main variant:
Internal storage:	512GB
MSRP:	$ 1399

Apple iPhone 16 Pro Max

With 1TB internal storage

Differences from the main variant:
Internal storage:	1024GB
MSRP:	$ 1599

Apple iPhone 16 Pro Max

International

Differences from the main variant:
5G:	Bands n1, n2, n3, n5, n7, n8, n12, n14, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD):	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 21(1500 Upper), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD):	Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 48(3600)
